Keysight N9918B 26.5 GHz FieldFox Microwave Analyzer

Keysight N9918B is the next-generation FieldFox Microwave Analyzer with an optional 100 MHz real-time bandwidth and frequency coverage up to 26.5 GHz. To address the millimeter wave frequency requirements for 5G, satellite, and automotive radar industries, FieldFox can easily extend its frequency up to 110 GHz with an add-on downconverter.

FieldFox is also the industry’s most integrated handheld analyzer supporting over 20 key RF and microwave instrument functions, including a signal analyzer, full 2-port vector network analyzer, real-time spectrum analyzer, and over-the-air demodulation, CW signal source, power meter, and many more, in an all-in-one field proof package.

Keysight N9918B can withstand your toughest working conditions with a ruggedized yet lightweight and portable battery-powered design for measuring RF devices like cables, antennas, filters, amplifiers, and signal/spectrum analysis. Create your specialized handheld analyzer solution by selecting FieldFox options and features to address cable and antenna test (CAT) spectrum analysis (SA) or vector network analysis (VNA) real-time spectrum analyzer and over-the-air digital demodulation analysis required for your application.

The FieldFox analyzers are always ready to make RF measurements, ensuring every operating mode is flexible enough to meet the needs of novices and experts.

Keysight N9918B Highlights

• The base model includes a cable and antenna analyzer.
• Capture intermittent signals with 100 MHz gap-free real-time bandwidth
• Supports over-the-air measurements for 5GTF and LTE
• 4 to 26.5 GHz, combo and SA versions (N9913B to N9918B and N9933B to N9938B).
• Increased real-time bandwidth. 10 MHz base, 40 MHz, and 100 MHz license key options.
• Same license key option features as the current “A” version, except no QuickCal.
• Improved spectrum analyzer DANL and phase noise
• Bigger battery
• Base “B” models will have a premium price compared to the base “A” models.
• “A” models will continue to be a great choice for many applications.
• Carry the world’s most integrated handheld RF analyzer: standard model includes cable and antenna analyzer.
• Expand capabilities with an optional vector network analyzer or spectrum analyzer
• Save time by measuring DTF and TDR in the same sweep
• GPS/GNSS receiver for geolocation and timestamping
• Simultaneously measure all four S-parameters with 115 dB system dynamic range
• Make accurate spectrum analyzer measurements (±0.3 dB) without warm-up
• Lightest all-in-one analyzer at 7.35 lb.

Why choose FieldFox?

• Ideal 5G deployment and field-testing tool with 100 MHz real-time bandwidth and over-the-air (OTA) measurements
• The ability for 5G, satellite and radar operators to make true RF coverage measurements, up to 54 GHz and beyond, and beamforming verification with phased array antenna support
• Simplified field signal monitoring with wideband capture and recording of fully corrected IQ data
• Highly efficient radar and EW systems diagnostics with spectrum analysis, full 2-port VNA, power meter, pulse, and noise figure measurements and results that correlate with high-performance benchtop instruments
• Durable handheld analyzers that can withstand your toughest working conditions

Designed for You and the Work You Do Everyday

• Carry FieldFox wherever you need to go
• Kit friendly at 3.34 kg for the N991B/3xB and N995xB/6xB
• Large buttons are easy to operate, even when wearing gloves
• Field swappable battery lasts up to 4 hours
• The non-slip rubber grip securely fits in your hands and won’t slide off your vehicle’s hood.
• A vertical “portrait” orientation makes it easy to hold and operate simultaneously.

Field-proof usability for better answers in less time

• Bright, low-reflection display and backlit keys enable easy viewing in direct sunlight or darkness
• The intuitively designed user interface for your workflow, enabling measurements in fewer key presses
• One-button measurements simplify complex setups and ensure quick, accurate results with confidence
• Calibration Wizard guides users to ensure simple and accurate calibrations
• A Standard three-year warranty ensures field confidence, especially in harsh environments

Designed for your Toughest Working Conditions

• A completely sealed instrument enclosure provides measurement stability in harsh environments, -10 to +55 ºC, (14 to 131 ºF)
• Specially designed to protect instruments from damage due to drops, shock, or other external impacts.
• Water-resistant chassis, keypad, and case withstand wide temperature ranges and salty, humid environments.
• Meets MIL-PRF-28800F Class 2 requirements
• Type tested and meets MIL-STD-810G, Method 511.5, Procedure I requirements for operation in explosive environments.
• Type tested and meets IEC/EN 60529 requirements for ingress protection.
