Tektronix RSA507A Real Time Spectrum Analyzer 9kHz – 7.5GHz

Tektronix RSA507A is a portable spectrum analyzer in the RSA500A series. The RSA507A USB spectrum analyzer offers high-performance portable spectrum analysis in a rugged battery-powered package. It was built to bring real-time spectrum analysis to help spectrum managers, interference hunters, and network maintenance personnel track down hard-to-find interferers, maintain RF networks, and keep records of their efforts. The heart of the system is the USB-based RF spectrum analyzer that captures 40 MHz of bandwidth with high fidelity in harsh environments.

The Tektronix RSA507A operates with SignalVu-PC, a powerful program that forms the basis of Tek’s traditional spectrum analyzer and offers deep analysis capabilities. It is used for spectrum management, interference hunting, and the maintenance, installation, and repair of radio networks.

Tektronix RSA507A Features:

• RSA507A: 9 kHz to 7.5 GHz
• 40 MHz acquisition bandwidth enables real-time analysis for transient capture and vector analysis
• High-speed full-span sweeps (70 GHz/sec) for fast setup and discovery
• Standard GPS/GLONASS/Beidou receiver for mapping and reference oscillator accuracy enhancement
• Optional tracking generator for gain/loss, antenna, and cable measurements
• DataVu-PC software enables multi-unit recording in variable bandwidths
• Mil-Std 28800 Class 2 environmental, shock, and vibration specifications for use in harsh conditions
• AC powered, or use an internal battery for extended field operations
• SignalVu-PC software* offers real-time signal processing with DPX Spectrum/Spectrogram to minimize time spent on transient and interference hunting
• EMC/EMI pre-compliance and troubleshooting – CISPR detectors, predefined standards, limit lines, easy accessory setup, ambient capture, failure analysis, and report generation
• Application programming interface included for the development of custom programs
• 15 µsec minimum signal duration with 100% probability of intercept ensures you see problems the first time, every time
• Accessories, including tablet PC, calibration kits, adapters, and phase stable cables, offer a complete field solution for interference hunting and transmitter maintenance
• Three-year warranty

The RSA500 delivers performance that matches conventional mid-range spectrum analyzers on the market. With real-time sweeps and a 4x faster scanning capability compared to other spectrum analyzers, you won’t miss signals you need to see and complete tasks faster. No compromises for even your toughest challenges.

RSA500A Series vs. Keysight FieldFox

Powerful and intuitive. Measurement insight at your fingertips.

The RSA Series is powered by SignalVu-PC Vector Analysis software, which provides:

• Advanced measurement and debugging capabilities – including advanced triggering that enables the capture of selective pulses from pulsed transmitters, as well as fast and elusive or unexpected transients during device troubleshooting.​
• Ability to control more than one RSA connected to the same PC to measure simultaneous events at different frequencies, such as harmonics and out-of-band emissions.
• A wide range of add-on packages is available, covering general-purpose modulation analysis, pulsed signal analysis, Bluetooth 5, and commercial wireless signal analysis.

Simplify your time in the field

With a built-in tracking generator for RF component test and GPS to geo-locate and map signals, the RSA500 makes field test a lot easier. Application-optimized software options for vector signal analysis, pulsed measurements, EMI/EMC pre-compliance testing, RADHAZ detection and more, make signal analysis a breeze.

Emission Control, Radiation Hazards, and the Value of Intelligent RF Sensing for These Applications

Simultaneous capture on multiple channels

Easily acquire, analyze, and visualize RF events across multiple frequencies using one or more instruments connected to a single PC.

See more with proprietary DPX® technology.

Discover the most difficult, hard-to-find problems with the powerful real-time architecture of the RSA Series. With the advanced DPX® technology, you can see RF characteristics that are practically invisible to a conventional spectrum analyzer.

Applications

• General-purpose spectrum analysis
• Radio network installation and maintenance
• Spectrum monitoring
• Spectrum management
• Interference hunting
• EMI/EMC compliance testing and troubleshooting
• Spectrum operations
• Radiation hazard (RADHAZ) testing
• Emissions control (EMCON) monitoring
• Signal intelligence (SIGINT) monitoring

Specifications:

• Brand: Tektronix
• Frequency Range: 4.0 – 8.0 GHz
• Maximum Frequency: 7.5 GHz
• Noise Floor: -155 dBm
• Product Type: USB
• Preamplifier: Yes
• Series: RSA500 Series
• Battery Life: 4 hrs.
• Battery Type: Li-Ion, Smart Battery compatible with SMBus interface.
• Includes: USB 3.0 cable (2 M), A-A connection, screw lock, shoulder strap, carrying case (with room for unit, tablet, accessories), quick-start manual (printed), connector covers, WFM200BA Li-Ion rechargeable battery pack, WFM200BA Li-Ion battery pack instructions
• Input Connector: BNC female, N type female
• Memory: 8 GB
• Minimum Frequency: 9 kHz
• Warranty: 3 Years

The Tektronix RSA507A 9 kHz to 7.5 GHz, 40 MHz Acquisition Bandwidth Portable USB Real Time Spectrum Analyzer was built to bring real-time spectrum analysis to solving the problems of spectrum managers, interference hunters, and network maintenance personnel who need to track down hard-to-find interferers, maintain RF networks, and keep records of their efforts.

The heart of the system is the USB-based RF spectrum analyzer that captures 40 MHz of real-time bandwidth with high fidelity in harsh environments. With 70 dB spurious-free dynamic range and frequency coverage to 7.5 GHz, all signals of interest can be examined with high confidence in your measurement results.

The USB form factor moves the weight of the instrument off of your hands and replaces it with a lightweight Windows tablet or laptop. Holding a light PC instead of a heavy spectrum analyzer means you can move faster for longer and get your work done faster.

The optional tracking generator (Option RSA507A 04) enables gain/loss measurements for quick tests of filters, duplexers, and other network elements, and you can add cable and antenna measurements of VSWR, return loss, distance to fault, and cable loss as needed.

Includes

• Tektronix RSA507A Unit
• Wireless Antenna
• Tektronix RF Cable
• Trimble GPS Antenna
• AC to DC Power Supply
• North American Power Cable
• USB Communication Cable
• Tektronix MAPFL-SVPC *Internal Option* Floating License: Adds Mapping
• Laptop
